RSO-1 200 |
RSO-2 400 |
RSO-3 600 |
RSO-4 800 |
RSO-6 1200 |
RSO-8 1600 |
RSO-10 2000 |
RSO-12 2400 |
| Max. Temperature |
140C |
140C |
140C |
140C |
140C |
140C |
140C |
140C |
| Max. Pressure kg/cm^2 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
| Liquid (Lit) |
600~1200 |
1200~2400 |
1800~3600 |
2400~4800 |
3600~7200 |
4800~9600 |
6000~12000 |
7200~14400 |
| Capacity (kg) |
160~200 |
320~400 |
480~600 |
640~800 |
960~1200 |
1280~1600 |
1600~2000 |
1920~2400 |
| Main pump motor (HP) |
15 |
30 |
40 |
50 |
60 |
75 |
100 |
125 |
| Heating rate 20C-130C/min |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
| Cooling rate 130C-80C/min |
15 |
15 |
15 |
15 |
15 |
15 |
15 |
15 |
| Fabric speed (m/min) |
700 |
700 |
700 |
700 |
700 |
700 |
700 |
700 |
| Steam (kg/cycle) |
273 |
547 |
820 |
1094 |
1641 |
2185 |
2730 |
3276 |
| Cooling water (Lit) |
1308 |
2616 |
3924 |
5232 |
7850 |
10465 |
13080 |
15700 |
| Space required M.M |
Length |
4962 |
4962 |
4962 |
4962 |
5297 |
6202 |
6202 |
6202 |
| Width |
2440 |
3313 |
4132 |
5275 |
7239 |
8750 |
11096 |
12222 |
| Height |
3050 |
3050 |
3050 |
3050 |
3050 |
3050 |
3050 |
3050 |
